Dimensional Drawings for E-Z LOK™ Inserts for Plastic

When you need to adhere to tight tolerances, it is essential to ensure that even the smallest parts meet your exact specifications. At E-Z LOK, we provide dimensional drawings for every part so that you can be sure that the one you purchase meets your exact specifications.

Phone: (800) 234-5613Plastic inserts:Threaded Inserts for Plastic

E-Z Press™ Inserts for Thermoset Plastics and Thermoplastics

SeriesStyleAlloyUOMDownload
240-BR SeriesFlushBrassInch & MetricDownload
240-CR SeriesFlushStainless SteelInch & MetricDownload
260-BR SeriesFlangedBrassInch & MetricDownload
260-CR SeriesFlangedStainless SteelInch & MetricDownload
260-RS SeriesReverse SlotBrassInchDownload
260-RS-CR SeriesReverse SlotStainless SteelInch & MetricDownload

E-Z Sonic™ Ultrasonic Inserts for Thermoplastics

StyleAlloyUOMDownload
TaperedBrassInch & MetricDownload
StraightBrassInchDownload
StraightStainless SteelInch & MetricDownload
